Symbols for Welding

A comprehensive implementation guide for the Symbols of Welding curriculum.

Complete Training Program Includes:

Streaming video access to 1 HIWT Course

  • Symbols for Welding (9 topics)

In addition to video access, you will receive detailed instructor guides for each course listed above, including lesson plans for each topic, a PDF quiz bank, answer keys, a student workbook, and a technical guide with additional content for each welding process covered.

You can add individual student workbooks and video access separately based on the quantity needed.



Price range: $295.00 through $895.00

Access Keys

Access keys provide individual users with streaming access to the videos.

Adjust the quantity at checkout to match the number of users who need access to the videos.

Additional Information

Here's a short demo clip:

https://vimeo.com/688375117

Topics
  1. Communicating Welding Information
  2. Fillet Welds
  3. Weld symbols for length and arrangement
  4. Supplementary symbols and reference
  5. Plug and slot welds
  6. Spot, Stud and seam welds
  7. Groove weld symbols
  8. Backing, back, melt-through and surfacing symbols
  9. Edge welds and combination weld symbols
